CompAir C55-14 -C76 Volume Flow 5.5 to 7.6m3/min & Operating Pressure 7 to 14 bar This new range of compressors stands out for its low diesel consumption, which is 10% less than the previous range. Equipped with a Diesel Particle Filter, these modern compressors are built to the latest emission standard Stage V. Thanks to a wide pressure range up to 14 bar, this compact compressor range is extremely versatile and meets the requirements of numerous applications.

Volume Flow 3.5 to 5m3/min & Operating Pressure 7 to 10 bar The highly successful CompAir range C35-10 to C50 is driven by exceptionally quiet-running, water-cooled Yanmar 4- cylinder diesel engines. The compressor is particularly suitable for applications in cities and built-up areas, where stringent restrictions are set on noise emissions.

A wide range of condensate treatment technologies Correctly discharging and disposing of the condensate which occurs in a compressed air network is a critical part of keeping the network functioning properly and at the the correct network pressure. This all too often overlooked part of the process is essential to keep the network running at peak efficiency, this section explains the role of the condensate drain in the compressed air network.

A filter range to rely on The reliability of compressed air filtration is paramount to the ongoing fight against problems caused through contamination entering the air system. The CompAir filter range has been constantly innovated and has become a leading technology, providing the exact balance between air quality, energy efficiency and low lifetime costs.

Superior control solution with great energy saving potential Compressed air systems typically comprise of multiple compressors delivering air to a common distribution system. The combined capacity of those machines is generally greater than the maximum site demand.

The cost-effective, reliable and safe solution for medium to large nitrogen requirements. CompAir offers an ideal solution with a comprehensive range of cost effective nitrogen generator systems from compressed air, that enable users to produce their total demand for nitrogen gas on their premises and under their control. Compared to traditional methods of supply, on-site nitrogen generator is exceptionally cost-efficient with a short payback time on investment - in many cases less than twelve months.

Water vapour is removed from compressed air by passing it over an adsorbent desiccant material. As the air contacts the adsorbent material, water vapour transfers from the wet air to the dry desiccant, however, adsorbent materials have a fixed adsorption capacity and once this capacity is reached, they must be regenerated or replaced. Therefore, to provide a continuous supply of clean, dry compressed air, adsorbent dryers utilise two chambers of desiccant material and at any one time, whilst one chamber is on-line, drying the incoming compressed air, the other is either off-line, being regenerated or is re- pressurised, ready to come on-line.

The CompAir AX-Series uses twin desiccant towers and strategically positioned valves to dry the compressed air. The compressed air produced is thoroughly dried as it is directed through the on-line desiccant-filled tower of the dryer. As the desiccant in this tower adsorbs moisture from the air, the desiccant in the dryer’s offline tower is purged of moisture and readied for use.

At the heart of any compressed air treatment solution is the dryer, it’s purpose, to remove water vapour, stop condensation, corrosion and in the case of adsorption dryers, inhibit the growth of micro- organisms. CompAir dryers have been 100% function and performance tested at our plant in Fogliano, Italy to ensure the highest standard of performance, delivering compressed air purity in accordance with ISO8573-1.2010, Class 2 dirt (1 micron) and Class 2 water (-40°C pressure dew point).

High-performance desiccant air treatment By combining the proven benefits of desiccant drying with modern design, CompAir provides an extremely compact and reliable system to dry and clean compressed air efficiently. The CompAir A-Series of heatless regenerative desiccant dryers have proven to be the ideal solution for many thousands of compressed air users worldwide in a wide variety of industries.

Vacuum Regeneration Adsorption Dryers Vacuum regeneration dryers do not use process air to regenerate the adsorbent desiccant material, instead they use ambient air for both regeneration and cooling (reducing energy consumption and process air loss). For regeneration, the ambient air is heated and pulled across the desiccant bed using a vacuum pump. To cool the desiccant and ensure it is at the optimum temperature for adsorption, the heat source is simply removed, and the desiccant cooled to ambient temperature. Vacuum regeneration dryers can be supplied with electric heaters or heat exchangers that utilise existing heat sources on site (steam, hot oil, etc.)

Energy Efficient CD-Series First-class air treatment efficiency The CD-Series refrigerant dryers are carefully selected depending on working conditions with continuous dew point monitoring enabling reliable operation with the lowest possible pressure losses and running costs. This range offers a wide range of kW sizes and caters for a larger range of airflows than the cycling dryer range.
